Thermal Imagers
Two-axis stabilized gimbals and black-box imagers combining a 1080p day camera with an LWIR or MWIR thermal channel, laser rangefinder and optional laser designator. Qualified to MIL-STD-810G tactical armored vehicle vibration and shock levels, with IMU and encoder based dual-loop stabilization and an on-board video tracker.
Thermal Spectral Band
Cooled MWIR
LWIR
LWIR
LWIR
Thermal Detector Resolution
1280 × 1024 px
640 × 512 px
640 × 512 px
1280 × 1024 px
Thermal NETD
≤ 20 mK
≤ 50 mK
≤ 50 mK
≤ 30 mK
EO Optical Zoom
Up to 90x
30x
30x
30x
Laser Rangefinder Range
—
Stabilization Accuracy
< 50 µrad
0.1°
0.05°
—
Positioning Accuracy
< 100 µrad
0.1°
0.04°
—
Weight
18.4 kg
4.4 kg
4.6 kg
< 8.0 kg
Height
155 mm
235 mm
256 mm
178 mm
Control Interface
RS-422
RS-485
RS-485
RS-422 / RS-485 / Ethernet
- QualificationMIL-STD-810G, tactical armored vehicle class
- Supply20–32 V
- Temperature−32 °C to +60 °C
- IPIP65
